Remanufactured Spot Film Devices
 Our
remanufactured spotfilm devices undergo a thorough cleaning
and inspection for overall unit integrity. All motors, relays,
solenoids, and pall mounts are tested and repaired or replaced
as required. The air check device, interrupter, and all wafer
decks are also inspected and tested for serviceability. Additionally,
the internal cassette carriage is inspected for fatigue and
excessive wear and is replaced as necessary.
All bearings, track surfaces, switches, pots, cables, springs
and associated parts and other controls are inspected and
replaced as required. The optional lead protective apron and
associated parts are refinished, and the entire unit undergoes
a complete cosmetic restoration. The system is then pre-staged
to its associated table and fully tested and calibrated to
OEM specifications.
Model 88/85 Spot-Film Device
- Accepts 9.5” X 9.5” or 24 cm X 24 cm cassette
sizes for operating simplicity and rapid access from fluoro
mode.
- Vertical Power Assist on all 9” and 12” image
system units.
- 1 on 1, 2 on 1 longitudinal and 4 on 1 spot film programs.
- Mini spot orthographic format of 6 on 1 manually sequenced.
- Rapid sequence spot films accomplished with 0.5 seconds
between exposures.
- Quantamat density control allows approximately ±
50% mAs.
- Effort sensing longitudinal power assist control built
into positioning handle.
Model 8835/8535 Spot-Film Device
- Compatible with 9.5” X 9.5”, 10” X 12”,
12” X 10”, 14” X 14” cassette sizes.
- Formats include 1:1, 2:1 lat, 2:1 long, 3:1 long, 4:1,
6:1, 9:1.
- Quantamatics exposure control.
- Ion chamber phototiming.
- Longitudinal power assist.
