Drying wire and cable can be a tricky, expensive business. Huestis Industrial Air Wipes
use precision controlled air flow to save air, reduce noise and dramatically cut energy
consumption.
Here are the basics of how an air wipe works:
Air is channeled through a manifold in the body and distributed to a ring of jets.
Jet orifices restrict air flow to provide efficient drying at the lowest possible
air consumption.
Turbulence created by controlling air flow and direction removes water from the
material surface.
A Venturi effect is also created within the air wipe, further increasing air flow.
Sizes are recommendations only. Specific applications may require less or greater
clearance for proper drying.
Custom openings up to 7" (177.8mm) in diameter
MINI Wipes™
Mini Wipe™
features protective ceramic inserts for bare wire applications.
Solid, low profile bodies easily fit into tight process lines...
Air Miser™ is the worldwide industry standard for
cost effective and reliable drying. Extremely efficient, it automatically passes knots and splices
and features quick bracket and air disconnects to make size changes a snap...
Our ceramic lined “air miser” has the exact same
profile as our standard air miser, with fully lined ceramic inserts.
You will enjoy the benefits of the original design having great drying properties while using
less air than other types of air wipers...
The “Down Drafter” was developed to answer the needs
of specialized extrusion, where blow back of liquids has to be minimized and avoided for improved drying
without disturbing the environment around it...
To order your own custom-designed air wipers, please call us at 401-253-5500 (800-972-9222 toll-free)
with your specific needs and we'll provide you with a price quote.
Mini Wipe™
features protective ceramic inserts for bare wire applications.
Solid, low profile bodies easily fit into tight process lines...
Air Miser™ is the worldwide industry standard for
cost effective and reliable drying. Extremely efficient, it automatically passes knots and splices
and features quick bracket and air disconnects to make size changes a snap...
Our ceramic lined “air miser” has the exact same
profile as our standard air miser, with fully lined ceramic inserts.
You will enjoy the benefits of the original design having great drying properties while using
less air than other types of air wipers...
The “Down Drafter” was developed to answer the needs
of specialized extrusion, where blow back of liquids has to be minimized and avoided for improved drying
without disturbing the environment around it...
Rectangular Wipe handles strip, flats and other profiles.
Standard models feature .125” - .250” (3.2 - 6.4 mm) high slot openings from 1.00” - 4.00”
